2016 65" TCL Xclusive X1 U65S9906 Specifications

Brand TCL
Type TV
Size 65" (inches)
Panel VA
Refresh Rate 120 Hz
Screen Aspect Ratio 16:9
Screen Resolution 3840 x 2160
General Info
Type TV
Year 2016
Brand TCL
Model Series S99
Model Number Xclusive X1 U65S9906
Alias U65S9906
Size 65" (inches)
Panel VA
Operating System Android 6.0 Marshmallow
Display
Screen Size Class 65" (inches)
Diagonal Size 64.53 in
163.9 cm
1639 mm
5.38 ft
Screen Width 56.24 in
142.8 cm
1428.48 mm
4.69 ft
Screen Height 31.63 in
80.4 cm
803.52 mm
2.64 ft
Display Curvature 4000
Display Type VA
Display Bit Depth 10 bits
Frame Rate Control Yes
Max Number of Colors 1073741824
Bits 30
Screen Aspect Ratio 16:9
Screen Resolution 3840 x 2160
Screen Pixel Pitch 0.372 mm
Screen Pixel Density 68 ppi
Screen-to-Body Ratio 87.95 %
Backlight Source Direct LED (Full-Array Local Dimming)
DCI P3 93%
Rec.2020 78
Max Screen Brightness 1000 cd/m²
Static Screen Contrast 10000 : 1
Screen Horizontal Viewing Angle 178 °
Screen Vertical Viewing Angle 178 °
Screen Input Lag 47 ms
Display Average Response Time 13 ms
HDR HDR10
3D No
Size, weight, color
Case Depth 4.8 in
12.2 cm
122 mm
0.4 ft
Case Weight 38.5 kg
85 lbs
Case Width with Stand 57.09 in
145 cm
1450 mm
4.76 ft
Case Height with Stand 37.8 in
96 cm
960 mm
3.15 ft
Case Depth with Stand 13.39 in
34 cm
340 mm
1.12 ft
Case Weight with Stand 39 kg
86 lbs
Case Color Black, White
Hardware
CPU Cores 4
RAM Memory Size 3
Internal Storage 16
TV Tuner Analog (NTSC/PAL/SECAM)
DVB-T2
DVB-S2
DVB-C
Built-in Camera No
Network LAN
Wi-Fi
802.11a (IEEE 802.11a-1999)
802.11b (IEEE 802.11b-1999)
802.11g (IEEE 802.11g-2003)
802.11n (IEEE 802.11n-2009)
802.11ac (IEEE 802.11ac)
Bluetooth
Wi-Fi Direct
DLNA
Connectivity 1 x Ethernet RJ45
4 x HDMI 2.0 (ARC; CEC; MHL)
1 x CI+
1 x AV Composite In (Video + L/R)
1 x S/PDIF
1 x AV Component In (YPbPr + L/R)
1 x Satellite In (Main; F-type female)
1 x USB 2.0
1 x 3.5 mm Audio Out
2 x USB 3.0 (max 1 A)
1 x Antenna (RF) (female)
Audio
Audio Speakers 2 x 20W
Features
OS Android 6.0 Marshmallow
Cool Features Mega Dynamic Contrast
Pure Image Ulra HD
Super Resolution EX
Ultra Local Dimming
UHD Color Extender
Quantum Dot LED
HDCP (High-bandwidth Digital Content Protection) 2.2
HDR Premium 1500
Ergonomics
Case Width 57.09 in
145 cm
1450 mm
4.76 ft
Case Height 35.43 in
90 cm
900 mm
2.95 ft
Vesa Mount Support Yes
VESA Interface Standard Size 400 x 200
Removable VESA Stand Yes
Height Adjustment No
Landscape or Portrait Pivot Support No
Left or Right Swivel Support No
Forward and Backward Tilt Support No
Frequency and Interpolation
Vertical Digital Frequency 120 Hz
Screen Interpolation Technology Picture Performance Index
Screen Interpolation Value 2600
Screen Interpolation Measurement Unit PPI
Power
220V 220 V - 240 V
AC Frequency 50 Hz - 60 Hz
Power Consumption When Device is Off 0.29 W
Power Consumption in Eco Mode 88 W
Maximum Power Consumption 160 W
Energy Class A+
Accessories
Extras Remote control - RC602S + RC802N
Certificates and Standards
Licenses RoHS
Usage and Storage Requirements
Safe Operating Temperature Level 5 °C - 35 °C
41 °F - 95 °F
Safe Operating Humidity Level 20 % - 75 %
Internal Storage Temperature -15 °C - 45 °C
5 °F - 113 °F
Internal Storage Humidity 10 % - 90 %
