2016 43" Panasonic TC-43DS630 Specifications

Brand Panasonic
Type TV
Size 43" (inches)
Panel IPS
Refresh Rate 60 Hz
Screen Aspect Ratio 16:9
Screen Resolution 1920 x 1080
General Info
Type TV
Year 2016
Brand Panasonic
Model Series DS630
Model Number TC-43DS630
Alias TC-43DS630C
Size 43" (inches)
Panel IPS
Display
Screen Size Class 43" (inches)
Diagonal Size 42.52 in
108 cm
1080 mm
3.54 ft
Screen Width 37.05 in
94.1 cm
941.184 mm
3.09 ft
Screen Height 20.84 in
52.9 cm
529.416 mm
1.74 ft
Display Type IPS
Display Bit Depth 8 bits
Frame Rate Control No
Max Number of Colors 16777216
Bits 24
Screen Aspect Ratio 16:9
Screen Resolution 1920 x 1080
Screen Pixel Pitch 0.49 mm
Screen Pixel Density 51 ppi
Screen-to-Body Ratio 92.77 %
Backlight Source Edge LED
Screen Horizontal Viewing Angle 178 °
Screen Vertical Viewing Angle 178 °
3D No
Size, weight, color
Case Depth 3.15 in
8 cm
80 mm
0.26 ft
Case Weight 9 kg
20 lbs
Case Width with Stand 37.17 in
94.4 cm
944 mm
3.1 ft
Case Height with Stand 24.21 in
61.5 cm
615 mm
2.02 ft
Case Depth with Stand 7.95 in
20.2 cm
202 mm
0.66 ft
Case Weight with Stand 10 kg
22 lbs
Case Color Gray
Hardware
System on Chip or SoC MediaTek MT5591
CPU ARM Cortex-A9
CPU Cores 2
CPU Frequency 1200
TV Tuner Analog (NTSC/PAL/SECAM)
Clear QAM
ATSC
Built-in Camera No
Network LAN
Wi-Fi
802.11a (IEEE 802.11a-1999)
802.11b (IEEE 802.11b-1999)
802.11g (IEEE 802.11g-2003)
802.11n (IEEE 802.11n-2009)
802.11n 5GHz
DLNA
Connectivity 2 x HDMI 1.4 (ARC; CEC)
1 x AV Composite In (Video + L/R)
1 x Optical Audio Out
1 x AV Component In (YPbPr + L/R)
1 x USB 2.0 (max 0.5 A)
1 x Ethernet RJ45
Audio
Audio Speakers 2 x 10W
Features
Cool Features Light sensor
my Home Screen 2.0
TV Anywhere
Voice command
Viera Link (HDMI CEC)
Super Bright Panel
Adaptive Backlight Dimming
V-Audio Surround
Hexa Chroma Drive
Ergonomics
Case Width 37.17 in
94.4 cm
944 mm
3.1 ft
Case Height 22.4 in
56.9 cm
569 mm
1.87 ft
Vesa Mount Support Yes
VESA Interface Standard Size 200 x 200
Removable VESA Stand Yes
Height Adjustment No
Landscape or Portrait Pivot Support No
Left or Right Swivel Support No
Forward and Backward Tilt Support No
Frequency and Interpolation
Vertical Digital Frequency 60 Hz
Screen Interpolation Technology Image Motion
Screen Interpolation Value 120
Screen Interpolation Measurement Unit IM
Power
110V 100 V - 120 V
AC Frequency 50 Hz - 60 Hz
Power Consumption When Device is Off 0.2 W
Power Consumption in Sleep Mode 0.2 W
Average Power Consumption 66.7 W
Maximum Power Consumption 100 W
Accessories
Extras Remote control - N2QAYB001013
Certificates and Standards
Usage and Storage Requirements
Safe Operating Temperature Level 0 °C - 35 °C
32 °F - 95 °F
Safe Operating Humidity Level 20 % - 80 %
