| Brand | LG |
| Type | TV |
| Size | 49" (inches) |
| Panel | IPS |
| Refresh Rate | 60 Hz |
| Min Response Time | 8 ms |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 3840 x 2160 |
| General Info | |
|---|---|
| Type | TV |
| Year | 2015 |
| Brand | LG |
| Model Series | UF690 |
| Model Number | 49UF690V |
| Size | 49" (inches) |
| Panel | IPS |
| Operating System | webOS 2.0 |
| Display | |
| Screen Size Class | 49" (inches) |
| Diagonal Size | 48.46 in 123.1 cm 1231 mm 4.04 ft |
| Screen Width | 42.27 in 107.4 cm 1073.78 mm 3.52 ft |
| Screen Height | 23.78 in 60.4 cm 604 mm 1.98 ft |
| Display Manufacturer | Newoptics |
| Display Type | IPS |
| Display Bit Depth | 8 bits |
| Frame Rate Control | Yes |
| Max Number of Colors | 16777216 |
| Bits | 24 |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 3840 x 2160 |
| Screen Pixel Pitch | 0.28 mm |
| Screen Pixel Density | 90 ppi |
| Screen-to-Body Ratio | 90.46 % |
| Backlight Source | Edge LED |
| NTSC 1953 | 68 % |
| Screen Brightness | 390 cd/m² |
| Static Screen Contrast | 1200 : 1 |
| Screen Horizontal Viewing Angle | 178 ° |
| Screen Vertical Viewing Angle | 178 ° |
| Display Minimum Response Time | 8 ms |
| 3D | No |
| Size, weight, color | |
| Case Depth | 2.31 in 5.9 cm 58.7 mm 0.19 ft |
| Case Weight | 13.1 kg 29 lbs |
| Case Width with Stand | 43.43 in 110.3 cm 1103 mm 3.62 ft |
| Case Height with Stand | 27.48 in 69.8 cm 698 mm 2.29 ft |
| Case Depth with Stand | 7.8 in 19.8 cm 198 mm 0.65 ft |
| Case Weight with Stand | 13.4 kg 29 lbs |
| Case Color | White |
| Hardware | |
| System on Chip or SoC | MStar LM15U |
| CPU | ARM Cortex-A12 |
| CPU Cores | 4 |
| CPU Frequency | 1100 |
| GPU | ARM Mali-T760 MP4 |
| GPU Cores | 4 |
| GPU Frequency | 550 |
| RAM Memory Size | 2.5 |
| Internal Storage | 4 |
| TV Tuner | Analog (NTSC/PAL/SECAM) DVB-T DVB-T2 DVB-S2 DVB-C |
| Built-in Camera | No |
| Network | LAN Wi-Fi 802.11a (IEEE 802.11a-1999) 802.11b (IEEE 802.11b-1999) 802.11g (IEEE 802.11g-2003) 802.11n (IEEE 802.11n-2009) 802.11n 5GHz Bluetooth Wi-Fi Direct DLNA |
| Connectivity | 1 x Ethernet RJ45 1 x HDMI 1.4 (CEC) 1 x RS232 (C) 1 x Satellite In (Main; F-type female) 1 x AV Composite In (Video + L/R) 1 x Antenna (RF) (female) 1 x SCART 1 x HDMI 2.0 (ARC; CEC; MHL) 1 x USB 2.0 1 x CI+ 1.3 1 x AV Component In (YPbPr + L/R) 1 x USB 3.0 1 x Optical Audio Out |
| Audio | |
| Audio Speakers | 2 x 5W |
| Features | |
| OS | webOS 2.0 |
| Cool Features | Clear Voice II Dynamic Clear White ULTRA Surround HDCP (High-bandwidth Digital Content Protection) SIMPLINK (HDMI CEC) Local Dimming Dynamic Color Enhancer 4K Upscaler Triple XD Engine Active Noice Reduction ULTRA HD Engine |
| Ergonomics | |
| Case Width | 43.43 in 110.3 cm 1103 mm 3.62 ft |
| Case Height | 25.59 in 65 cm 650 mm 2.13 ft |
| Vesa Mount Support | Yes |
| VESA Interface Standard Size | 300 x 300 |
| Removable VESA Stand | Yes |
| Height Adjustment | No |
| Landscape or Portrait Pivot Support | No |
| Left or Right Swivel Support | No |
| Forward and Backward Tilt Support | No |
| Frequency and Interpolation | |
| Vertical Digital Frequency | 60 Hz |
| Screen Interpolation Technology | Picture Mastering Index |
| Screen Interpolation Value | 700 |
| Screen Interpolation Measurement Unit | PMI |
| Power | |
| 110V | 100 V - 120 V |
| 220V | 220 V - 240 V |
| AC Frequency | 50 Hz - 60 Hz |
| Power Consumption in Sleep Mode | 0.3 W |
| Maximum Power Consumption | 68 W |
| Energy Class | A+ |
| Accessories | |
| Extras | Remote control - AN-MR500 |
| Certificates and Standards | |
| Licenses | RoHS UL/cUL |
| Usage and Storage Requirements | |
| Safe Operating Temperature Level | 0 °C - 40 °C 32 °F - 104 °F |
| Safe Operating Humidity Level | 10 % - 80 % |
| Internal Storage Temperature | -20 °C - 60 °C -4 °F - 140 °F |
| Internal Storage Humidity | 5 % - 85 % |
