| Brand | NEC |
| Type | Monitor |
| Size | 24" (inches) |
| Panel | IPS |
| Refresh Rate | 75 Hz |
| Min Response Time | 6 ms |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 1920 x 1080 |
| General Info | |
|---|---|
| Type | Monitor |
| Year | 2020 |
| Brand | NEC |
| Model Series | MultiSync |
| Model Number | MultiSync EA242F-BK-SV |
| Size | 24" (inches) |
| Panel | IPS |
| Display | |
| Screen Size Class | 24" (inches) |
| Diagonal Size | 23.78 in 60.4 cm 604 mm 1.98 ft |
| Screen Width | 20.75 in 52.7 cm 527.04 mm 1.73 ft |
| Screen Height | 11.67 in 29.6 cm 296.46 mm 0.97 ft |
| Display Type | IPS |
| Display Bit Depth | 8 bits (6 bits + FRC) |
| Frame Rate Control | Yes |
| Max Number of Colors | 16777216 |
| Bits | 24 |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 1920 x 1080 |
| Screen Pixel Pitch | 0.275 mm |
| Screen Pixel Density | 92 ppi |
| Screen-to-Body Ratio | 91.06 % |
| Backlight Source | W-LED |
| sRGB | 101.6 % |
| Adobe RGB 1998 | 75.3 % |
| NTSC 1953 | 72 % |
| Screen Brightness | 250 cd/m² |
| Static Screen Contrast | 1000 : 1 |
| Screen Horizontal Viewing Angle | 178 ° |
| Screen Vertical Viewing Angle | 178 ° |
| Display Minimum Response Time | 6 ms |
| Display Coating | Anti-glare/Matte (3H) |
| 3D | No |
| Size, weight, color | |
| Case Depth | 1.8 in 4.6 cm 45.6 mm 0.15 ft |
| Case Weight | 4.5 kg 10 lbs |
| Case Width with Stand | 21.17 in 53.8 cm 537.7 mm 1.76 ft |
| Case Height with Stand | 13.25 in 33.7 cm 336.6 mm 1.1 ft |
| Case Depth with Stand | 9.84 in 25 cm 250 mm 0.82 ft |
| Case Weight with Stand | 7 kg 15 lbs |
| Case Color | Black, White |
| Hardware | |
| Built-in Camera | No |
| Connectivity | 1 x USB 3.1 (Type-C; upstream; 65W) 1 x HDMI 1.4 1 x DVI-D 1 x 3.5 mm Audio Out 1 x D-sub 1 x DisplayPort 1.2 3 x USB 3.1 (Type-A; downstream) 1 x USB 3.1 (Type-B; upstream) |
| Audio | |
| Audio Speakers | 2 x 1W |
| Features | |
| Cool Features | ControlSync Dynamic Visual Mode SpectraView II Human sensor NaViSet Administrator 2 XtraView Light sensor EcoModes Ambix Picture-by-Picture Carbon Footprint Meter Rapid Response |
| Extra Features | Anti-theft stand lock slot - Kensington |
| Ergonomics | |
| Case Width | 21.17 in 53.8 cm 537.7 mm 1.76 ft |
| Case Height | 12.56 in 31.9 cm 319.1 mm 1.05 ft |
| Vesa Mount Support | Yes |
| VESA Interface Standard Size | 100 x 100 |
| Removable VESA Stand | Yes |
| Height Adjustment | Yes |
| Height Adjustment Range | 150 mm 15 cm 5.9055 in 0.4921 ft |
| Landscape or Portrait Pivot Support | Yes |
| Left Pivot | 90 ° |
| Right Pivot | 90 ° |
| Left or Right Swivel Support | Yes |
| Left Swivel | 170 ° |
| Right Swivel | 170 ° |
| Forward and Backward Tilt Support | Yes |
| Forward Tilt | 5 ° |
| Backward Tilt | 35 ° |
| Frequency and Interpolation | |
| Vertical Digital Frequency | 50 Hz - 75 Hz |
| Horizontal Digital Frequency | 31.5 kHz - 83 kHz |
| Screen Interpolation Measurement Unit | NULL |
| Power | |
| 110V | 100 V - 120 V |
| 220V | 220 V - 240 V |
| AC Frequency | 50 Hz - 60 Hz |
| Electric Power in Amperes | 0.9 A |
| Power Consumption When Device is Off | 0.3 W |
| Power Consumption in Sleep Mode | 0.3 W |
| Average Power Consumption | 19 W |
| Accessories | |
| Extras | DisplayPort cable DVI cable USB cable |
| Certificates and Standards | |
| Licenses | CE ENERGY STAR 8.0 ErP FCC Class B ISO 9241-307 MPR II / MPR III RoHS TCO Certified Displays 8.0 TÜV Rheinland Flicker Free TÜV Rheinland Low Blue Light UL/cUL |
| Usage and Storage Requirements | |
| Safe Operating Temperature Level | 5 °C - 35 °C 41 °F - 95 °F |
| Safe Operating Humidity Level | 20 % - 80 % |
| Internal Storage Temperature | -10 °C - 60 °C 14 °F - 140 °F |
| Internal Storage Humidity | 10 % - 85 % |
| Max Operating Altitude | 5000 |
| Max Storage Altitude | 12192 |
