| Brand | Dell |
| Type | Monitor |
| Size | 30" (inches) |
| Panel | IPS |
| Refresh Rate | 86 Hz |
| Min Response Time | 6 ms |
| Screen Aspect Ratio | 16:10 |
| Screen Resolution | 2560 x 1600 |
| General Info | |
|---|---|
| Type | Monitor |
| Year | 2016 |
| Brand | Dell |
| Model Number | UP3017 |
| Size | 30" (inches) |
| Panel | IPS |
| Display | |
| Screen Size Class | 30" (inches) |
| Diagonal Size | 29.77 in 75.6 cm 756.2 mm 2.48 ft |
| Screen Width | 25.25 in 64.1 cm 641.3 mm 2.1 ft |
| Screen Height | 15.78 in 40.1 cm 400.8 mm 1.31 ft |
| Display Type | IPS |
| Display Bit Depth | 10 bits (8 bits + FRC) |
| Frame Rate Control | Yes |
| Lut | 3D LUT 14 bits |
| Max Number of Colors | 1073741824 |
| Bits | 30 |
| Screen Aspect Ratio | 16:10 |
| Screen Resolution | 2560 x 1600 |
| Screen Pixel Pitch | 0.251 mm |
| Screen Pixel Density | 101 ppi |
| Screen-to-Body Ratio | 83.69 % |
| Backlight Source | W-LED |
| DCI P3 | 99% |
| sRGB | 99 % |
| Adobe RGB 1998 | 99 % |
| Screen Brightness | 350 cd/m² |
| Static Screen Contrast | 1000 : 1 |
| Screen Horizontal Viewing Angle | 178 ° |
| Screen Vertical Viewing Angle | 178 ° |
| Display Minimum Response Time | 6 ms |
| Display Average Response Time | 8 ms |
| Display Coating | Anti-glare/Matte (3H) |
| 3D | No |
| Size, weight, color | |
| Case Depth | 2.28 in 5.8 cm 58 mm 0.19 ft |
| Case Weight | 6.49 kg 14 lbs |
| Case Width with Stand | 27.04 in 68.7 cm 686.9 mm 2.25 ft |
| Case Height with Stand | 18.99 in 48.2 cm 482.3 mm 1.58 ft |
| Case Depth with Stand | 8.54 in 21.7 cm 217 mm 0.71 ft |
| Case Weight with Stand | 9.59 kg 21 lbs |
| Case Color | Black |
| Hardware | |
| Built-in Camera | No |
| Connectivity | 2 x HDMI 1.4 1 x DisplayPort 1.2 1 x DisplayPort 1.2 (Output MST) 1 x 3.5 mm Audio Out 1 x DisplayPort 1.2 (Input mini) 2 x USB 3.0 (downstream) 1 x USB 3.0 (upstream) |
| Audio | |
| Features | |
| Cool Features | Picture-in-Picture HDCP (High-bandwidth Digital Content Protection) Picture-by-Picture |
| Extra Features | Security lock slot |
| Ergonomics | |
| Case Width | 27.04 in 68.7 cm 686.9 mm 2.25 ft |
| Case Height | 17.6 in 44.7 cm 447.1 mm 1.47 ft |
| Vesa Mount Support | Yes |
| VESA Interface Standard Size | 100 x 100 |
| Removable VESA Stand | Yes |
| Height Adjustment | Yes |
| Height Adjustment Range | 150 mm 15 cm 5.9055 in 0.4921 ft |
| Landscape or Portrait Pivot Support | Yes |
| Left Pivot | 90 ° |
| Right Pivot | 90 ° |
| Left or Right Swivel Support | Yes |
| Left Swivel | 30 ° |
| Right Swivel | 30 ° |
| Forward and Backward Tilt Support | Yes |
| Forward Tilt | 5 ° |
| Backward Tilt | 21 ° |
| Frequency and Interpolation | |
| Vertical Digital Frequency | 50 Hz - 86 Hz |
| Horizontal Digital Frequency | 30 kHz - 113 kHz |
| Power | |
| 110V | 100 V - 120 V |
| 220V | 220 V - 240 V |
| AC Frequency | 50 Hz - 60 Hz |
| Electric Power in Amperes | 1.6 A |
| Power Consumption When Device is Off | 0.3 W |
| Power Consumption in Sleep Mode | 0.3 W |
| Average Power Consumption | 54 W |
| Power Consumption in Eco Mode | 38.2 W |
| Maximum Power Consumption | 108 W |
| Accessories | |
| Extras | DisplayPort cable - mini-DP to DP Factory Calibration Report USB 3.0 upstream cable |
| Certificates and Standards | |
| Licenses | CECP CEL ENERGY STAR 6.0 Epeat Gold RoHS Compliant TCO Certified Displays |
| Usage and Storage Requirements | |
| Safe Operating Temperature Level | 0 °C - 35 °C 32 °F - 95 °F |
| Safe Operating Humidity Level | 10 % - 80 % |
| Internal Storage Temperature | -20 °C - 60 °C -4 °F - 140 °F |
| Internal Storage Humidity | 5 % - 90 % |
| Max Operating Altitude | 5000 |
| Max Storage Altitude | 12192 |
