| Brand | AOC |
| Type | Monitor |
| Size | 24" (inches) |
| Panel | PLS |
| Refresh Rate | 80 Hz |
| Min Response Time | 4 ms |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 3840 x 2160 |
| General Info | |
|---|---|
| Type | Monitor |
| Year | 2015 |
| Brand | AOC |
| Model Number | U2477PWQ |
| Size | 24" (inches) |
| Panel | PLS |
| Display | |
| Screen Size Class | 24" (inches) |
| Diagonal Size | 23.58 in 59.9 cm 599 mm 1.97 ft |
| Screen Width | 20.52 in 52.1 cm 521.28 mm 1.71 ft |
| Screen Height | 11.54 in 29.3 cm 293.22 mm 0.96 ft |
| Display Manufacturer | Samsung |
| Display Type | PLS |
| Display Bit Depth | 8 bits |
| Frame Rate Control | No |
| Max Number of Colors | 16777216 |
| Bits | 24 |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 3840 x 2160 |
| Screen Pixel Pitch | 0.136 mm |
| Screen Pixel Density | 187 ppi |
| Backlight Source | W-LED |
| sRGB | 100 % |
| NTSC 1953 | 72 % |
| Screen Brightness | 300 cd/m² |
| Static Screen Contrast | 1000 : 1 |
| Dynamic Screen Contrast | 50000000 : 1 |
| Screen Horizontal Viewing Angle | 178 ° |
| Screen Vertical Viewing Angle | 178 ° |
| Screen Input Lag | 5 ms |
| Display Minimum Response Time | 4 ms |
| Display Maximum Response Time | 14 ms |
| Display Coating | Anti-glare/Matte (3H) |
| 3D | No |
| Size, weight, color | |
| Case Width with Stand | 21.85 in 55.5 cm 555 mm 1.82 ft |
| Case Height with Stand | 15.08 in 38.3 cm 383 mm 1.26 ft |
| Case Depth with Stand | 5.47 in 13.9 cm 139 mm 0.46 ft |
| Case Weight with Stand | 6 kg 13 lbs |
| Case Color | Black |
| Hardware | |
| Built-in Camera | No |
| Connectivity | 1 x DVI-D Dual Link 1 x D-sub 1 x HDMI 2.0 (MHL) 1 x DisplayPort 1.2 |
| Audio | |
| Features | |
| Cool Features | Flicker-free technology HDCP (High-bandwidth Digital Content Protection) |
| Ergonomics | |
| Vesa Mount Support | No |
| VESA Interface Standard Size | 100 x 100 |
| Removable VESA Stand | Yes |
| Height Adjustment | Yes |
| Height Adjustment Range | 130 mm 13 cm 5.1181 in 0.4265 ft |
| Landscape or Portrait Pivot Support | Yes |
| Left Pivot | 0 ° |
| Right Pivot | 90 ° |
| Left or Right Swivel Support | No |
| Forward and Backward Tilt Support | Yes |
| Forward Tilt | 5 ° |
| Backward Tilt | 23 ° |
| Frequency and Interpolation | |
| Vertical Digital Frequency | 23 Hz - 80 Hz |
| Horizontal Digital Frequency | 30 kHz - 160 kHz |
| Power | |
| 110V | 100 V - 120 V |
| 220V | 220 V - 240 V |
| AC Frequency | 50 Hz - 60 Hz |
| Power Consumption When Device is Off | 0.3 W |
| Power Consumption in Sleep Mode | 0.5 W |
| Average Power Consumption | 34 W |
| Accessories | |
| Extras | D-sub cable DisplayPort cable HDMI cable |
| Certificates and Standards | |
| Licenses | CE EAC ENERGY STAR 6.0 TCO Certified Displays 6.0 |
| Usage and Storage Requirements | |
| Safe Operating Temperature Level | 0 °C - 40 °C 32 °F - 104 °F |
| Safe Operating Humidity Level | 10 % - 85 % |
| Internal Storage Temperature | -25 °C - 55 °C -13 °F - 131 °F |
| Internal Storage Humidity | 5 % - 93 % |
| Max Operating Altitude | 3657.6 |
| Max Storage Altitude | 12192 |
