| Brand | AOC |
| Type | Monitor |
| Size | 22" (inches) |
| Panel | VA |
| Refresh Rate | 75 Hz |
| Min Response Time | 6.5 ms |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 1920 x 1080 |
| General Info | |
|---|---|
| Type | Monitor |
| Year | 2020 |
| Brand | AOC |
| Model Number | 22B1HM5 |
| Alias | 22B1HM5/D |
| Size | 22" (inches) |
| Panel | VA |
| Display | |
| Screen Size Class | 22" (inches) |
| Diagonal Size | 21.46 in 54.5 cm 545 mm 1.79 ft |
| Screen Width | 18.84 in 47.9 cm 478.656 mm 1.57 ft |
| Screen Height | 10.25 in 26 cm 260.28 mm 0.85 ft |
| Display Type | VA |
| Display Bit Depth | 8 bits (6 bits + FRC) |
| Frame Rate Control | Yes |
| Max Number of Colors | 16777216 |
| Bits | 24 |
| Screen Aspect Ratio | 16:9 |
| Screen Resolution | 1920 x 1080 |
| Screen Pixel Pitch | 0.249 mm |
| Screen Pixel Density | 102 ppi |
| Screen-to-Body Ratio | 88.84 % |
| Backlight Source | W-LED |
| sRGB | 99 % |
| Screen Brightness | 250 cd/m² |
| Static Screen Contrast | 3000 : 1 |
| Dynamic Screen Contrast | 20000000 : 1 |
| Screen Horizontal Viewing Angle | 178 ° |
| Screen Vertical Viewing Angle | 178 ° |
| Display Minimum Response Time | 6.5 ms |
| Display Coating | Anti-glare/Matte (3H) |
| 3D | No |
| Size, weight, color | |
| Case Depth | 1.48 in 3.8 cm 37.6 mm 0.12 ft |
| Case Weight | 2.01 kg 4 lbs |
| Case Width with Stand | 19.38 in 49.2 cm 492.2 mm 1.61 ft |
| Case Height with Stand | 14.96 in 38 cm 380 mm 1.25 ft |
| Case Depth with Stand | 7.31 in 18.6 cm 185.8 mm 0.61 ft |
| Case Weight with Stand | 2.24 kg 5 lbs |
| Case Color | Black |
| Hardware | |
| Built-in Camera | No |
| Connectivity | 1 x 3.5 mm Audio Out 1 x HDMI 1.4 1 x D-sub |
| Audio | |
| Features | |
| Cool Features | Dynamic Colour Boost (DCB) technology Dynamic Contrast Ratio (DCR) technology HDR Mode Low Blue Light Flicker-free technology Clear Vision DDC2B/CI |
| Extra Features | Anti-theft stand lock slot - Kensington |
| Ergonomics | |
| Case Width | 19.38 in 49.2 cm 492.2 mm 1.61 ft |
| Case Height | 11.22 in 28.5 cm 284.9 mm 0.93 ft |
| Vesa Mount Support | Yes |
| VESA Interface Standard Size | 100 x 100 |
| Removable VESA Stand | Yes |
| Height Adjustment | No |
| Landscape or Portrait Pivot Support | No |
| Left or Right Swivel Support | No |
| Forward and Backward Tilt Support | Yes |
| Forward Tilt | 5 ° |
| Backward Tilt | 20 ° |
| Frequency and Interpolation | |
| Vertical Digital Frequency | 48 Hz - 75 Hz |
| Horizontal Digital Frequency | 30 kHz - 85 kHz |
| Screen Interpolation Measurement Unit | NULL |
| Power | |
| 110V | 100 V - 120 V |
| 220V | 220 V - 240 V |
| AC Frequency | 50 Hz - 60 Hz |
| Electric Power in Amperes | 1.31 A |
| Power Consumption in Sleep Mode | 0.3 W |
| Average Power Consumption | 20 W |
| Accessories | |
| Extras | D-Sub cable |
| Certificates and Standards | |
| Licenses | CCC CE CECP CEL CH RoHS cTUVus FCC ISO 9241-307 Win10 |
| Usage and Storage Requirements | |
