| General Info | ||
|---|---|---|
| Model Number | Dell UP3017Q | EIZO FlexScan EV3285 |
|
|
|
| Price | ||
| Type | Monitor | Monitor |
| Year | 2017 | 2018 |
| Brand | Dell | EIZO |
| Model Number | UP3017Q | FlexScan EV3285 |
| Alias | EV3285-BK EV3285-WT |
|
| Display | ||
| Screen Size Class | 30" (inches) | 32" (inches) |
| Diagonal Size | 30 in 76.2 cm 761.9 mm 2.5 ft |
31.54 in 80.1 cm 801 mm 2.63 ft |
| Screen Width | 27.55 in 70 cm 699.86 mm 2.3 ft |
27.46 in 69.7 cm 697.4 mm 2.29 ft |
| Screen Height | 14.93 in 37.9 cm 379.22 mm 1.24 ft |
15.47 in 39.3 cm 392.85 mm 1.29 ft |
| Display Type | OLED | IPS |
| Display Bit Depth | 10 bits | 8 bits |
| Frame Rate Control | Yes | No |
| Lut | 3D LUT 14 bits |
|
| Max Number of Colors | 1073741824 | 16777216 |
| Bits | 30 | 24 |
| Screen Aspect Ratio | 16:9 | 16:9 |
| Screen Resolution | 3840 x 2160 | 3840 x 2160 |
| Screen Pixel Pitch | 0.182 mm | 0.182 mm |
| Screen Pixel Density | 139 ppi | 140 ppi |
| Screen-to-Body Ratio | 95.4 % | 91.74 % |
| Backlight Source | W-LED | |
| DCI P3 | 97.5% | 75% |
| Rec.2020 | 85.8 | |
| sRGB | 100 % | 100 % |
| Adobe RGB 1998 | 100 % | 75 % |
| Screen Brightness | 300 cd/m² | 350 cd/m² |
| Static Screen Contrast | 1300 : 1 | |
| Screen Horizontal Viewing Angle | 178 ° | 178 ° |
| Screen Vertical Viewing Angle | 178 ° | 178 ° |
| Screen Input Lag | 35 ms | |
| Display Minimum Response Time | 5 ms | |
| Display Average Response Time | 8 ms | |
| Display Maximum Response Time | 15 ms | |
| Display Coating | Anti-glare/Matte (2H) | |
| 3D | No | No |
| Size, weight, color | ||
| Case Depth | 1.76 in 4.5 cm 44.7 mm 0.15 ft |
2.03 in 5.2 cm 51.5 mm 0.17 ft |
| Case Weight | 6.43 kg 14 lbs |
7.6 kg 17 lbs |
| Case Width with Stand | 27.02 in 68.6 cm 686.2 mm 2.25 ft |
28.24 in 71.7 cm 717.4 mm 2.35 ft |
| Case Height with Stand | 17.96 in 45.6 cm 456.3 mm 1.5 ft |
16.82 in 42.7 cm 427.3 mm 1.4 ft |
| Case Depth with Stand | 7.54 in 19.2 cm 191.6 mm 0.63 ft |
9.06 in 23 cm 230 mm 0.75 ft |
| Case Weight with Stand | 11 kg 24 lbs |
|
| Case Color | Black | Black, White |
| Hardware | ||
| Built-in Camera | No | No |
| Connectivity | 1 x DisplayPort 1.2 1 x USB 3.0 (Type-C) 1 x HDMI 2.0 |
2 x HDMI 1 x DisplayPort 1.2 1 x 3.5 mm Audio Out 2 x USB 2.0 (downstream) 1 x USB 3.1 (Type-C) |
| Audio | ||
| Audio Speakers | 2 x 1W | |
| Features | ||
| Cool Features | HDCP (High-bandwidth Digital Content Protection) | HDCP (High-bandwidth Digital Content Protection) Light sensor Low Blue Light EcoView Flicker-free technology |
| Extra Features | Security lock slot | |
| Ergonomics | ||
| Case Width | 27.02 in 68.6 cm 686.2 mm 2.25 ft |
28.24 in 71.7 cm 717.4 mm 2.35 ft |
| Case Height | 15.96 in 40.5 cm 405.4 mm 1.33 ft |
16.39 in 41.6 cm 416.3 mm 1.37 ft |
| Vesa Mount Support | Yes | Yes |
| VESA Interface Standard Size | 100 x 100 | 100 x 100 |
| Removable VESA Stand | Yes | Yes |
| Height Adjustment | Yes | Yes |
| Height Adjustment Range | 100 mm 10 cm 3.937 in 0.3281 ft |
149 mm 14.9 cm 5.8661 in 0.4888 ft |
| Landscape or Portrait Pivot Support | Yes | No |
| Left Pivot | 90 ° | |
| Right Pivot | 90 ° | |
| Left or Right Swivel Support | No | Yes |
| Left Swivel | 172 ° | |
| Right Swivel | 172 ° | |
| Forward and Backward Tilt Support | Yes | Yes |
| Forward Tilt | 5 ° | 5 ° |
| Backward Tilt | 21 ° | 35 ° |
| Frequency and Interpolation | ||
| Vertical Digital Frequency | 60 Hz | 29 Hz - 71 Hz |
| Horizontal Digital Frequency | 31 kHz - 135 kHz | |
| Accessories | ||
| Extras | DisplayPort cable Factory Calibration Report HDMI cable USB 3.0 cable |
DisplayPort cable HDMI cable USB Type-C cable |
| Certificates and Standards | ||
| Licenses | CECP CEL ENERGY STAR 6.0 RoHS Compliant TCO Certified Displays |
CB CE cTÜVus EAC ENERGY STAR Epeat Gold FCC Class B ICES-003-B RCM RoHS TCO Displays 7.0 TÜV/Ergonomics TÜV/GS VCCI-B WEEE |
| Usage and Storage Requirements | ||
| Safe Operating Temperature Level | 0 °C - 35 °C 32 °F - 95 °F |
0 °C - 35 °C 32 °F - 95 °F |
| Safe Operating Humidity Level | 10 % - 80 % | 20 % - 80 % |
| Internal Storage Temperature | -20 °C - 60 °C -4 °F - 140 °F |
-20 °C - 60 °C -4 °F - 140 °F |
| Internal Storage Humidity | 5 % - 90 % | 10 % - 90 % |
| Max Operating Altitude | 5000 | |
| Max Storage Altitude | 12192 |
| Dell UP3017Q | EIZO FlexScan EV3285 |
